Hydraulic Vibroflot with 220 kN Centrifugal Force 20 m³/min Air Compressor and 500-800 mm Diameter for High Compaction Efficiency

Hydraulic Vibroflot with 220 kN Centrifugal Force 20 m³/min Air Compressor and 500-800 mm Diameter for High Compaction Efficiency

Ονομασία μάρκας: BVEM
Αριθμός μοντέλου: BJVH-350-150
Τροποποιημένο: 1
τιμή: 35000 $
Πληροφορίες συσκευασίας: ξύλινη θήκη
Όροι πληρωμής: L/C,T/T
Λεπτομέρειες
Τόπος καταγωγής:
ΚΙΝΑ
Πιστοποίηση:
CE、ISO 9001:2000、ISO 9001:2008
Αεροσυμπιεστής:
20 M3/Min
Τύπος:
Υδραυλικός
Εφαρμογή:
εδαφολογική βελτίωση
Μέθοδος:
Δονητική συμπίεση ή αντικατάσταση
Διάμετρος σωρός:
500-800 χιλ.
Δύναμη Δονητή:
150kW
δονητή μήκος:
2250 χιλ.
Πακέτο δύναμης:
176 KW
Εξωτερική διάμετρο:
350 mm
Σύστημα Ελέγχου:
Τηλεχειριστήριο
Φυγόκεντρη δύναμη κραδασμών:
220 kN
Δυνατότητα προσφοράς:
600 σετ/Έτος
Επισημαίνω:

Hydraulic Vibroflot with 220 kN centrifugal force

,

Hydraulic Vibroflot with 20 m³/min air compressor

,

Hydraulic Vibroflot for high compaction efficiency

Περιγραφή του προϊόντος
Hydraulic Vibroflot with 220 kN Centrifugal Force
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified
Product Overview

With over 50 years of dedication to the vibroflotation industry, BVEM has focused on R&D and investment in vibroflotation products. Our BJVH-350-150 hydraulic vibroflot represents the culmination of technical expertise and innovation, delivering high-efficiency, stable performance for demanding vibroflotation projects.

Working Principle

This hydraulic vibroflot efficiently converts hydraulic energy into mechanical energy (rotational motion) through a hydraulic motor, driving the eccentric block to generate strong horizontal excitation force. Key advantages include:

  • Large output torque for demanding applications
  • Wide speed regulation range with stepless control
  • Excellent impact load resistance
  • Stable power output for consistent performance
Key Features
  • 0-2900rpm stepless speed regulation: Flexible operation matching various construction requirements and soil conditions
  • Wide stratum compatibility: Optimized design provides strong penetration in both soft soil and gravel-containing strata
  • Continuous high-power output: Ensures stable operation and improved project efficiency
  • Water-cooled motor not required: Enables dry method environmental protection construction
  • High adaptability: Compatible with various equipment including pump stations, rotary drilling rigs, excavators, and pile frames
Certifications
CE Certified ISO 9001 Made in China
Applications

The BVEM Hydraulic Vibroflot (Model: BJVH-350-150) is designed for soil improvement across multiple construction scenarios:

  • Foundation Construction: Compacts soil to ensure stable building foundations
  • Road and Highway Projects: Enhances soil strength and reduces settling for durable infrastructure
  • Retaining Wall Installation: Improves soil stability and prevents erosion
Technical Evolution

BVEM has pioneered advancements in vibroflot technology, including:

  • Transition from electric to hydraulic driving systems
  • Development of both orifice filling and bottom discharge models
  • Expansion of mounting scenarios for diverse construction needs

This equipment provides contractors and engineers with a reliable, high-performance solution for soil improvement projects, combining quality construction with operational efficiency.
